DC 4.5V Rechargeable 10W Pupillary Distance Machine 30cm Distance

Place of Origin China
Certification CE
Model Number GD8405
Minimum Order Quantity 5pcs
Price Negotiable
Packaging Details 32 x 22 x 16cm; 1.5kgs.
Delivery Time 10-20 work days
Payment Terms L/C, Western Union, T/T
Supply Ability 500pcs/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
PD Measurement Binocular/Monocular VD Measuring Available
Automatic Switch Off Available Compensation Unit Included
Accuracy 0.5mm Steps Battery Type DC 4.5V Rechargeable Battery
Binocular Pupillary Distance From 45-80mm Left Or Right Pupillary Distance From 22.5-40mm
High Light

10W Pupillary Distance Machine


DC 4.5V Pupillary Distance Machine


Rechargeable Pupillary Distance Machine

Leave a Message
Product Description

CP-32AT Digital Pupilometer Binoculus PD 45-80mm PD MeterDC 4.5V rechargeable battery Power 10W




The PD Meter is a digital precision optical instrument used to measure distance
between human pupils in the process of optometry for fitting spectacles.

1, It employs precise optical structure, the line of light is very clear and precise measurement.The measurement results are displayed digitally,and the left eye and right eye measuring values are displayed separately.
2, Simple and rapid measuring operation, and free operation of the direct PD adjustment lever are possible.Combining with the adjustable viewing distance selecting lever for measuring all kind of the viewing distances, the PD measurement is simple and precise.
3, When the measuring operation is finished, the auto poweroff and memory function,enable to save the power and not to lose the data.
4, It can also be used in monocular the left eye and right eye separately.



Binocular pupillary distance: 45-80mm
Left or right pupillary distance: 22.5-40mm
Indication error: 0.5mm
Distance of targent: 30cm
Electric Voltage: DC 4.5V rechargeable battery
Power: 10W
Weight: 0.6kg
Volume: 21.5(L)x15(w)x50(H)cm

DC 4.5V Rechargeable 10W Pupillary Distance Machine 30cm Distance 0DC 4.5V Rechargeable 10W Pupillary Distance Machine 30cm Distance 1


DC 4.5V Rechargeable 10W Pupillary Distance Machine 30cm Distance 2

DC 4.5V Rechargeable 10W Pupillary Distance Machine 30cm Distance 3





DC 4.5V Rechargeable 10W Pupillary Distance Machine 30cm Distance 4
