Classic Appearance Optometry Phoropter Wide Range Of Auxiliary Lens Combinations

Basic Information
Place of Origin: China
Certification: CE, FDA
Model Number: GD8702B
Minimum Order Quantity: 1pcs
Price: Negotiable
Delivery Time: 10-20 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300pcs/month
Detail Information
Color: White And Black Quality: Top-grade Quality
Sphere Powers: +16.75D To-19.00D Cylinder Power Range: 0 To-6.00D
Astigmatic Axis Scale: 0 To 180° In 5° Steps Cross Cylinder: ±0.25D
Rotary Prism: 0 To 20D In 1D Step Rotary Prism: 0~20∆D In 1∆D Step
High Light:

digital phoropter


optometric instruments

Product Description

Hot Sell View Tester Optometry Phoropter Fully Sealed Vision Tester View Tester Refractor Two colors for Option GD8702B


1. Classic appearance, professional technology, precise measurement, easy and convenient operating, and best price value
2. All the lens are anti-reflection coated.
3. All Cross-Cylinder lens are Manus lens
4. New leveling mechanism
5. Fingertip adjustment for sphere power control
6. Unique new convergence system mechanism
7. Wide range of auxiliary lens combinations
8. Precision machined to finest tolerances
9. This is suitable for eyesight examination in spectacles shops, department of ophthalmology in hospitals, schools and enterprises
10. Two colors choice


Sphere powers range

+16.75D to-19.00D, with minimum reading 0.25D or 0.12D
(When +0.12D auxiliary lens or optional±0.12D lens is in use)
+26.75D to-29.00D (When optional ±10.00D lens is in use)

Cylinder power range

0 to-6.00D, with minimum reading 0.25D or 0.12D (when auxiliary lens is in use)
0 to-8.00D (when-2.00D auxiliary lens is in use)

Astigmatic axis scale0 to 180° in 5° steps
Cross cylinder±0.25D, reversal type (synchronized with astigmatic axis)
Rotary prism0 to 20D in 1D step
Interpupillary adjustment48mm to 80mm in 1mm step (right and left synchronized)
Forehead rest adjustment16mm backward and forward
ConvergenceThe optical axes of the lenses are aligned at a distance of 400mm from the vertexes of the corneas (2mm each for right and left inward)
Interpupillary distance enabling convergence57mm to 80mm
Corneal distance device2mm forward and 5mm backward from standard plane; with scale
Effective field of view19mm
